Typical application areas
For flexing applications
Without influence of oil
Preferably indoor applications
Especially for unsupported travels
Wood/stone processing, packaging industry, supply systems, handling, adjusting equipment
EMAIL:info@aein-cable.com
Typical application areas
•Conform to UL&CUL standard UL758,CSA C22.2 No. 210
•Conform to 2014/35/EU-Guideline (''Low voltage Directive'') CE
•We are pleased to produce special versions, other dimensions, core and jacket colours on request.
|
Min. bend radius, e-chain® (factor) |
15.0 x d |
|
Min. bend radius, e-chain® |
5.3 inch (135.0 mm) |
|
Min. bend radius, flexible (factor) |
12.0 x d |
|
Min. bend radius, flexible |
4.3 inch (108.0 mm) |
|
Min. bend radius, fixed (factor) |
8.0 x d |
|
Min. bend radius, fixed |
2.8 inch (72.0 mm) |
|
Temperature, e-chain® min. |
41 °F (5 °C) |
|
Temperature, e-chain® max. |
158 °F (70 °C) |
|
Temperature, flexible |
+23 °F to +158 °F (-5°C to +70°C) |
|
Temperature, fixed |
+5 °F to +158 °F (-15 °C to +70 °C) (following DIN EN 50305) |
|
v max., unsupported |
10 ft/s (3 m/s) |
|
a. max. |
65.6 ft/s² (20 m/s²) |
|
Length of travel |
Unsupported up to 33 ft (10 m) |
|
Conductor |
Conductor consisting of bare copper wires (according to DIN EN 60228) |
|
Conductor insulation |
Mechanically high-quality, especially low-capacitance TPE mixture |
|
Conductor construction |
Cores stranded in optimized pitch |
|
Conductor identification |
Cores black with white numerals, one core green-yellow. |
|
Unshielded |
Yes |
|
|
Outer jacket |
Low adhesion mixture on the basis of PVC, adapted to suit the requirements in e-chains® |
|
Jacket color |
Pastel orange (similar to RAL 2003) |
